St Francis 50

Modern ocean sailing catamaran
US$1,310,000.00 (Approx £1,000,496)
  • Boat REF#  ·  314101
  • Length  ·  15.25m
  • Year  ·  New
  • Construction  ·  Composite
  • Underwater profile  ·  Multihull
  • Sleeping berths  ·  8
  • Engine  ·  2 x diesel 57hp, Yanmar 4JH57-Cr 57HP with SD60 Sail Drives
  • Lying  ·  Eastern Cape
Boatshed New Build Boats
Boatshed New Build Boats
Bruce Stirk

Meet the Builder

St Francis catamarans

St Francis 50

Want to hear from the builders of the St Francis boats? See our exclusive interview with them now.

Lifestyle & Use

This is a modern, sophisticated vessel with all the comforts of your home. The large saloon area is perfect for entertaining, dining, and everyday living. Each of the cabins have exceptional ventilation and natural lighting from the forward facing hatches, queen sized beds, hanging closets and en-suite bathrooms. Each bathroom features its own shower, basin, vanity cabinet and electric toilet.

Unique Features

The St Francis 50 is made to cross oceans and can easily make passages averaging 200 plus nautical miles per day. She is easy to handle and its comfortable seating area gives you an almost perfect panorama of the outside. The additional buoyancy in the sterns allows for a bigger tender to be lifted and stored with the davit system.

Design & Build

The designer, Angelo Lavranos, has designed an excellent craft which construction and integrity as well as her seaworthiness has been endorsed by many sailors. This new design offers improved speed, reduced transom immersion and disturbance, better overall motion characteristics, better looks, and bigger platform space.

Prices & Process

The price for the St Francis 50 starts at US$ 1 230 000.00. Each St Francis is custom built with a vast choice of layouts, leather or fabric colours, countertop finishes, and wood grains. As would be expected the pricing of the vessel will be amended to reflect the final build specification agreed to between the boatyard & purchaser.

Extra Details

Designer Angelo Lavranos
Builder St Francis Marine
Lying Eastern Cape
Fuel capacity 880.0 ltr (193.6 USG) Total - 4 Tanks
Water capacity 1,350.0 ltr (297.0 USG) Total - 2 Tanks
Holding tank capacity 550.0 ltr (121.0 USG) Total - 2 Tanks

Mechanical

Engine 2 x diesel 57hp
Engine make and model Yanmar 4JH57-Cr 57HP with SD60 Sail Drives
Engine Hours Not Recorded
Engine Cooled Indirect
Steering wheel
Drive saildrive
Prop(s) 2 x Gori 20" x 16" x 3-bladed left hand rotating f
Fuel consumption (approx) Not Recorded
Water-maker

2 x Sun Power Maxeon Solar panels (2 x 400 watt, total 800 watts) each with Smart Solar 75/15 MPPT.
Kohler Generator 9EKOZD 8.5KW 110V @ 60Hz.
Victron Quattro Inverter/Charger 12/5000/120.

Dimensions

Length 15.25m
LWL 14.35m
Beam 8.00m
Draft Min 1.25m
Airdraft 21.52m

Rig

Sloop rigged Sparcraft Aluminium spars with Stainless Steel standing rigging

Sails

Reefing mainsail North Sails - SlabStack Pack, Fully Battened, Lazy Jacks,
Headsail North Sails - Furling
Other sails Storm Jib

Mainsail - North Sails Pinhead Tour Xi Norlam Xi11/09, 3 x Reefs 6 x Battens.
Fully battened with lazy jacks & stackpack (St Francis logo on stackpack).
Furling Genoa - North Sails Tour Xi Norlam Xi09 RopeLuff Pad & Roller Reef structure, UV Protection Leech and foot.
Storm Jib - North Sails Polyester High Visibility 10oz Storm Orange.
Gennaker - North Sails G2 Cruising Nylon 150/250 with Snuffer.
Code Zero - North Sails Stormlite 510/210.

Electrical Systems

12 volt battery, 110 / 240 shore power voltage, 5 batteries charged by: engine, solar panels, shore power, generator

Construction

Construction Composite
Underwater profile Multihull
Finish Paint finish

New vertical Bow profile.
Vinyl ester (Epoxy based resin) infused Core cell foam sandwich.
E-glass stitched quadriaxial non-crimp fabric throughout construction.
All strong points Carbon Fibre reinforced.
Aluminium fender rubbing strake with pvc inlay on hull/deck joint.
4 Coats Osmosis Protection Epoxy Primer.
2 Coats Awlgrip Epoxy coatings Spray system (Matterhorn White).

Accommodation

Total # of berths 8
No. of double berths 4
Cabin(s) 4
Sink 4
Shower 4
Heads 4 heads (Electric)

1 x 160L Isotherm S/ Steel double drawer freezer in Port Side Companionway.
1 x 190L Isotherm S/ Steel double drawer fridge.
Double sinks with Pull-out mixer tap, alongside drying cupboard with electric fan.
Corian chopping boards to cover sinks when not in use.
Trash hole with cover integrated in galley top for ease of cleaning.
Ample cupboard & drawer space.
Solid Surfacing tops (Corian).
Flooring - Vinyl.
Spice Rack
Large sliding window in galley for access between Galley & Cockpit dining area.
Cupboard above deepfreeze

Accommodation

Broiler
Oven
Sink
Refrigerator
Freezer
Manual water system
Pressurised water system
Hot water system
Fresh water wash
Raw water wash
Cockpit shower

1 x 160L Isotherm S/ Steel double drawer freezer in Port Side Companionway.
1 x 190L Isotherm S/ Steel double drawer fridge.
Double sinks with Pull-out mixer tap, alongside drying cupboard with electric fan.
Corian chopping boards to cover sinks when not in use.
Trash hole with cover integrated in galley top for ease of cleaning.
Ample cupboard & drawer space.
Solid Surfacing tops (Corian).
Flooring - Vinyl.
Spice Rack
Large sliding window in galley for access between Galley & Cockpit dining area.
Cupboard above deepfreeze

Deck Gear

Sail cover
Fenders
Swim Ladder
Instrument Covers
Bimini

1 halyard winches
2 sheet winches
Electric 1 x Maxwell HRC10-10 Electric Anchor Windlass windlass
2 anchors
(Rocna and secondary Fortress)
100.00m of chain
2 X 50 ST 2 speed (Manual Aluminium Self Tailing) Primary Winches.
1 x 46 ST (Manual Aluminium Self Tailing) main traveller & roller furling Winch.
1 x 46 ST (Manual Aluminium Self Tailing) halyard & boom extension Winch at mast.
3 x 10" lock in handles.
1 x 33kg Rocna galvanised anchor 100m x 10mm test chain.
1 x 9kg FX 37 - Secondary Fortress anchor, 10m x 8mm chain & 30m X 16mm Mooring warp.
16mm mooring warps 3 x 9m 3 x 16m.
6 x cylindrical fenders
Para anchoring & Anchor Bridle mounting points on crossbeam.
Maxwell AA560 Chain Counter at helm.
Anchor Bridle & Chain Swivel connector.

Nav Equipment

Compass
Speed
Log
Wind
VHF DSC radio
GPS
Chart plotter
Autopilot
Navigation lights
TV
AIS Receiver
Depth sounder

B&G V60-B: VHF DSC Radio fixed mount with integrated AIS transmitter& Receiver, Wireless Handset support.
B&G H60 Wireless handset for V60F radio.
B&G Zeus S-12 Chartplotter Steering Station.
B&G NAC-3 Autopilot Core Pack, High current NC3 Autopilot computer, Precision 9 compass & RF-25 rudder feedback unit.
B&G Triton Autopilot controller& 4.1" display pack
B&G Zeus S-12 and Halo20 + Radar kit.
Wind Vane.
EC1-100 Universal engine & control interface.

Safety Equipment

Fume detector
Carbon Monoxide detector
Liferaft
Life jackets
Life buoys
Danbuoy
Safety harnesses
Horn
EPIRB 406MHz
Emergency steering

6 bilge pumps (2 manual / 4 electric)

4 x Grey Water Whale Pumps.
2 x 275L (73 gal) holding tanks & electric Macerator pumps (WEMA monitored).
2 x Shurflo Fresh water pressure pumps.
2 x Whale Manual Bilge Pumps.
4 x1100 gph Rule Auto Electric bilge pumps with float switches and alarms.
